Original code 60000033Band connection, flow rate 70l/h, balanced by-pass, fittings 3/8 "GAS/BSP, NSF, compact format, size without pin 58,5mm
Balanced by pass. Fitting 3/8"GAS, code 9R10-P, total lenght 99mm, body lenght 86mm AISI 304.Suitable for Cimbali, La Marzocco and Nuova Simonelli coffee machines.Alternative code 9V0104The serial code identifying the model, date of manufacture, and all information about the pump is printed on the rectangular label at the bottom of the pump.If the label has been removed, the warranty will not be recognized.
Original code 30400055Suitable for Crem Expobar (mod. EB61, G10, Megacrem, Monroc, New Elegance, Office) coffee machines
Max pressure 15 bar, Max flow rate 650 cc/min. Input with hose connection, output 1/8"GAS. Correct working: 2 min. ON / 1 min. OFF. Suitable to Olympia (Maximatic) coffee machine.
Self-priming in counter pressure conditions. Same 9V00357 principle valve but superior performance and durability.IN 1/8" GAS - OUT rubber hose d.7mm, gasket NBR, temp: 35°C Max.
Balanced by-pass. Direct coupling to motor without joint. Suitable to Casadio (DIECIA, DIECIS), Cimbali (M24,M39,,M39GT) e Faema (EMBLEMA, ENOVA).
Reduced dimensions. Standard by-pass.Suitable for Crem Expobar, La Nuova Era, Cime, La Rocca, XLVI coffee machines.Fitting 3/8"GAS: code 9R10-PPump shaft cod. 9V10307The serial code identifying the model, date of manufacture, and all information about the pump is printed on the rectangular label at the bottom of the pump.If the label has been removed, the warranty will not be recognized.
Original code 30000240Suitable for Crem Expobar (mod. Diamant, EB61, Elen, G10, Markus, Markus silver, Megacrem, Monroc, New Elegance, Office) coffee machines.Alternative code 8W56116-P
